3D Modeling

3D Measurement

3D Points measured with the Total Station can be edited and processed into a geometric mesh or a set of 3D curves.

Meshes are processed into NURB surfaces in Rhino®, creating accurate 3D surface models.


• Reverse Engineering
• Ship Geometry Checks
• As-is Line Drawings
• Modification and Restoration

3D curves & meshes may also be created by digitizing paper drawings: This service can be provided on a case-by-case basis.
